Sunon MF40101V2-1000U-G99 Axial fan 12 V DC 11.89 m³/h (L x W x H) 10 x 40 x 40 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
12 V DC
Power
0.48 W
Type of bearing
Vapo (magnetic)
Air flow rate
11.89 m³/h
Datasheet (PDF)
Technical specifications
- Connection type: UL1007 AWG26 wires, stripped, tin-plated
- Product type
Axial fan
- Type
MF40101V2-1000U-G99
- Nominal voltage
12 V DC
- Min. operating voltage
6 V DC
- Max. operating voltage
13.8 V DC
- Operating voltage
6 - 13.8 V DC
- Max. current consumption
0.04 A
0.48 W
- Type of bearing
Vapo (magnetic)
- Rotational speed
5800 U/min
- Noise emission (max.)
20.6 dB
- Air flow rate
11.89 m³/h
- Connection
Braid
- Pressure (max.)
29.88 Pa
- Factory colour
Black
- Material
Thermoplastic
70000 h
- Weight
17.61 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
10 mm
- Width
40 mm
- Height
40 mm
- Dim
(L x W x H) 10 x 40 x 40 mm
