Sunon MF80252V3-1000U-A99 Axial fan 24 V DC 56.05 m³/h (L x W x H) 25 x 80 x 80 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
24 V DC
Power
0.96 W
Type of bearing
Vapo (magnetic)
Air flow rate
56.05 m³/h
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.08
3
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.08 / piece)
€ 10.08
plus VAT.
14-day return policy included
Technical specifications
- Connection type: Strands UL1007 AWG24, stripped, tin-plated
- Product type
Axial fan
- Type
MF80252V3-1000U-A99
- Nominal voltage
24 V DC
- Min. operating voltage
10 V DC
- Max. operating voltage
27.6 V DC
- Operating voltage
10 - 27.6 V DC
- Max. current consumption
0.04 A
0.96 W
- Type of bearing
Vapo (magnetic)
- Rotational speed
2600 U/min
- Noise emission (max.)
28 dB
- Air flow rate
56.05 m³/h
- Connection
Braid
- Pressure (max.)
27.39 Pa
- Factory colour
Black
- Material
Thermoplastic
70000 h
- Weight
89.88 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
25 mm
- Width
80 mm
- Height
80 mm
- Dim
(L x W x H) 25 x 80 x 80 mm
Documents & Downloads
Datasheet
Datasheet 2992711 Sunon MF80252V3-1000U-A99 Axial fan 24 V DC 56.05 m³/h (L x W x H) 25 x 80 x 80 mm
User & Safety Instructions
User & Safety Instructions 2992711 Sunon MF80252V3-1000U-A99 Axial fan 24 V DC 56.05 m³/h (L x W x H) 25 x 80 x 80 mm
