Sunon SP101A-1123HST.GN Axial fan 115 V AC 144.38 m³/h (L x W x H) 38 x 120 x 120 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
115 V AC
Power
20 W
Type of bearing
Plain bearing
Air flow rate
144.38 m³/h
Datasheet (PDF)
Technical specifications
- Connection type: Integrated spade connectors (2.8x0.5mm)
- Product type
Axial fan
- Type
SP101A-1123HST.GN
- Nominal voltage
115 V AC
- Min. operating voltage
85 V AC
- Max. operating voltage
125 V AC
- Operating voltage
85 - 125 V AC
- Max. current consumption
0.21 A
20 W
- Type of bearing
Plain bearing
- Rotational speed
2550 U/min
- Noise emission (max.)
43 dB
- Air flow rate
144.38 m³/h
- Connection
Type C CEE 7/16 plug 2.8 mm
- Pressure (max.)
62.25 Pa
- Factory colour
Black
- Material
Aluminium (die-cast)
Thermoplastic
- Weight
537.5 g
- Min. temperature
-10 °C
- Max. temperature
70 °C
- Length
38 mm
- Width
120 mm
- Height
120 mm
- Dim
(L x W x H) 38 x 120 x 120 mm
