Susumu RG1608P-752-B-T5 SMD resistor 7.5 kΩ SMD 0603 0.1 W 0.1 % 25 ppm/°C 1 pc(s) #####Tape and Reel
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
SMD resistor
Type
0603
Resistance
7.5 kΩ
Power rating
0.1 W
Datasheet (PDF)
Highlights & Details
Susumu SMD thin film 0603 0.1W 0.1% 7K5
Our service for you
Technical specifications
- Application: For all applications that require precision resistances, such as: Automotive electronics, industrial measurement technology and entertainment electronics
- ESD Packaging: No ESD
- Series RG1608P
- Design 0603
- Delivery type: Belt
- Resistance tolerance: ±0.1 %
- Rated output: 0.1 W
- Load reduction: Linear from 85°C to 155°C (0W)
- Max. OPERATING VOLTAGE (DC) 100 V DC
- Max. OPERATING VOLTAGE (AC) 100 V AC
- Qualification: AEC-Q200
- Packaging type
#####Tape and Reel
- Product type
SMD resistor
- Type
SMD
- Type
0603
- Resistance
7.5 kΩ
- Power rating
0.1 W
- Tolerance ±
0.1 %
- Temperature coefficient
25 ppm/°C
- Length
1.6 mm
- Width
0.8 mm
- Height
0.4 mm
- Content
1 pc(s)
- Dim
(L x W x H) 1.6 x 0.8 x 0.4 mm
- RoHS-compliant
Yes
- Type
RG1608P-752-B-T5
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3465009 Susumu RG1608P-752-B-T5 SMD resistor 7.5 kΩ SMD 0603 0.1 W 0.1 % 25 ppm/°C 1 pc(s) #####Tape and Reel
User & Safety Instructions
User & Safety Instructions 3465009 Susumu RG1608P-752-B-T5 SMD resistor 7.5 kΩ SMD 0603 0.1 W 0.1 % 25 ppm/°C 1 pc(s) #####Tape and Reel
Description
Susumu RG 1608P thin film precision W.
This text is machine translated.
This text is machine translated.
Features
- • SMD precision thin film resistor
- • Low temperature coefficient (TC = ±25ppm/°C)
- • Low tolerance of 0.1%
- • Very good compatibility with overvoltages
