SWG Hox 17901614016 Countersunk screws 6 mm 140 mm Star DIN 18360 Steel zinc plated 10 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SWG Hox 17901614016 wood screw 6x140mm HX30 internal drive
- The nominal diameter of 6 mm provides a firm grip in wooden structures and improves the load transfer during screwing. The nominal length of 140 mm allows you to penetrate thicker cross-sections for secure connections in long wooden components. The internal HX30 drive reduces the risk of over-turning during machine assembly and supports a uniform torque. Supplied in 10 pack, Ideal for smaller projects and simple storage.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
140 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 140 mm
- DIN standard
DIN 18360
- Content
10 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595347 SWG Hox 17901614016 Countersunk screws 6 mm 140 mm Star DIN 18360 Steel zinc plated 10 pc(s)
User & Safety Instructions
User & Safety Instructions 3595347 SWG Hox 17901614016 Countersunk screws 6 mm 140 mm Star DIN 18360 Steel zinc plated 10 pc(s)
Information
Test Summary Report 3595347 SWG Hox 17901614016 Countersunk screws 6 mm 140 mm Star DIN 18360 Steel zinc plated 10 pc(s)
Conformity certificate
Conformity certificate 3595347 SWG Hox 17901614016 Countersunk screws 6 mm 140 mm Star DIN 18360 Steel zinc plated 10 pc(s)
Description
This wood screw is a threaded fixing element for connecting wooden components. It converts the torque into an axial clamping force. The internal HX30 drive is compatible with compatible hexagonal bits, enabling safe turning with motor-driven or manual screwdrivers. The shape and length of the thread provide a progressive stripping resistance when screwing into the wood and thus also secure overlapping or stacked wooden parts. The screw is supplied in a practical pack size and is suitable Ideal for applications requiring deep screw-in depth in wood, which must ensure reliable mechanical connection and even assembly behavior.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 140 mm
- Type/Size name: 6x140
- Internal drive: HX30
- Contents: 10 pieces
