Image similar
Image similar
Switching power supply MEAN WELL LDB-600LW 72-144 V 1050 mA 18 W 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- protection class: IP67
- Output voltage (max.)
30 V DC
- Output voltage (min.)
2 V DC
- Connection
Open end cable
- Dim
(L x W x H) 31.8 x 20.3 x 12.2 mm
- Weight
18 g
- Content
1 pc(s)
- Width
20.3 mm
- Height
12.2 mm
- Length
31.8 mm
- Type
LDB-600LW
- Type
constant current
- No. of inputs
1 x
- No. of outputs
1 x
18 W
- Output voltage
72-144 V
- Output current (details)
1050 mA
- Type
Synchronised
- Type
switched-mode
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1371716 Switching power supply MEAN WELL LDB-600LW 72-144 V 1050 mA 18 W 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1371716 Switching power supply MEAN WELL LDB-600LW 72-144 V 1050 mA 18 W 1 pc(s)
Information
Information 1371716 Switching power supply MEAN WELL LDB-600LW 72-144 V 1050 mA 18 W 1 pc(s)
Warranty Terms
Warranty Terms 1371716 Switching power supply MEAN WELL LDB-600LW 72-144 V 1050 mA 18 W 1 pc(s)
Description
Constant voltage-switching power supply in waterproof plastic enclosure (IP67) with an input voltage range of 180-305 V/AC.
Features
- universal input
- plastic enclosure IP67
- overload protection, current limiting, auto recovery
- protections: short circuit/over load/over voltage
- protection class 2
- fixed output current
Hints
Devices only for use in equipment with another primary purpose such as photocopiers, overhead projectors and slide projectors or for scale illumination or indication purposes. Suitable for indoor use and outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes.
