TDK-Lambda DRL60-12-1 Rail mounted PSU (DIN) 12 V 4.5 A 54 W Content 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 50.41 / piece)
€ 50.41
plus VAT.
Highlights & Details
DIN-Rail Power Supply; DRL-60-12-1
- 12 V/ 4.5 A
- 54 W Power
- Temperature range -40 - 85 °C
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
85 V AC
- Input voltage (max.)
264 V AC
- Max. output current
4.5 A
- Output current (max.) - rounded
4.5 A
54 W
- Output voltage (nominal)
12 V
- Dim
(L x W x H) 55.6 x 54 x 91 mm
- Weight
200 g
- Output voltage (max.)
15 V
- Output voltage (min.)
12 V
- Operating temperature (max.)
71 °C
- Operating temperature (min.)
-25 °C
- Manufacturer part #
DRL60-12-1
- Content
1 pc(s)
- Width
54 mm
- Height
91 mm
- Length
55.6 mm
- Max. temperature
85 °C
- Min. temperature
-40 °C
- Type
DRL60-12-1
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1885059 TDK-Lambda DRL60-12-1 Rail mounted PSU (DIN) 12 V 4.5 A 54 W Content 1 pc(s)
Warranty Terms
Warranty Terms 1885059 TDK-Lambda DRL60-12-1 Rail mounted PSU (DIN) 12 V 4.5 A 54 W Content 1 pc(s)
Description
The S DRL-DIN rail power supply series is suitable for building automation and, in particular, for the narrow spaces in meter locations, distribution boxes or sub-distributions. It provides 10 - 100 W output power, meets the ErP efficiency guidelines and is controlled by a network-wide range input (85-264 V AC). All four performance classes are available with 24 VDC nominal output voltage available, there are also 12 V DC models with 10, 30 and 60 W output power. All models (except the 10 W devices) have trimmbare outputs. The S DRL series has a protection class II structure (protective insulation) and therefore requires no protective earth conductor. The test voltage between input and output is 3 kV AC. All models are convection cooled and for operating temperatures between -20°C and +71°C. In addition, the series with longlife electrolytic capacitors.
