TDK PXG-M20-48WS05 DC/DC converter 5 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DC-DC, PCB PCB PCB mounting, input 18-75VDC, output 5V 4A, 20W
- Wide 4:1 input voltage range
- Standard 1.6" x 1" format
- Certified according to IEC 60601-1 and IEC 62368-1
- 2x MOPP insulation
- Low idle power consumption
Technical specifications
- Product type
DC/DC converter
- Type
PXG-M20-48WS05
- Nominal voltage
5 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
4 A
- Output current (max.) - rounded
4 A
20 W
- Operating temperature (min.)
-55 °C
- Operating temperature (max.)
+125 °C
- Dim
(L x W x H) 40.6 x 25.4 x 10.2 mm
- Height
10.2 mm
- Length
40.6 mm
- Width
25.4 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5 V DC
- Weight
24 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2481344 TDK PXG-M20-48WS05 DC/DC converter 5 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2481344 TDK PXG-M20-48WS05 DC/DC converter 5 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2481344 TDK PXG-M20-48WS05 DC/DC converter 5 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
The PXG-M series is a 1.6x1" DC-DC converter with IEC 60601-1 approvals for medical devices and IEC 62368-1 for audio/video, information and communication technology. Equipped with an isolation voltage primary/secondary of 5000Vac, the series offers 4:1 wide-range inputs with 9 to 36VDC or 18 to 75Vdc and output voltages of 5, 12, 15, 24, +/- 5, +/- 12 and +/- 15Vdc.
