TDK VLCF4020T-2R2N1R7 SMD / SMT-Induktivitäten Inductor shielded SMD 10 µH 0.185 Ω 1.22 A 1 pc(s) Tape on Full reel
Part number:
Item no:
Packaging type
Tape on Full reel
Product type
Inductor
Type
SMD
Inductance (L)
10 µH
Resistance
0.185 Ω
Datasheet (PDF)
Number
Tape on Full reel
Piece(s) (Content: )
Piece(s) (Content: )
Total (€ 0.31 / piece)
€ 0.31
plus VAT.
Highlights & Details
TDK inductance VLCF4020T-2R2N1R7
- Magnetically shielded inductivity for power circuits.
- Flat design
- Magnetically shielded version with ferrite core.
- Operating temperature range: - 40 to +105 °C (incl. self-heating)
- Ferrite winding
- VCF series
- This text is machine translated.
Our service for you
Technical specifications
- Packaging type
Tape on Full reel
- Product type
Inductor
- Features
shielded
- Type
SMD
- Inductance (L)
10 µH
- Frequency
100 kHz
- Test frequency
100 kHz
- Sample rate
100 kHz
- Tolerance ±
20 %
- Resistance
0.185 Ω
- Nominal current
1.22 A
- Material
Duplex steel
- Length
4 mm
- Width
4 mm
- Height
2 mm
- Min. temperature
-40 °C
- Max. temperature
105 °C
- Weight
0.112 g
- Industrial packaging
Yes
- Content
1 pc(s)
- Dim
(L x W x H) 4 x 4 x 2 mm
- RoHS-compliant
Yes
- Type
SMD / SMT-Induktivitäten
Documents & Downloads
Datasheet
Datasheet 3555324 TDK VLCF4020T-2R2N1R7 SMD / SMT-Induktivitäten Inductor shielded SMD 10 µH 0.185 Ω 1.22 A 1 pc(s) Tape on Full reel
User & Safety Instructions
User & Safety Instructions 3555324 TDK VLCF4020T-2R2N1R7 SMD / SMT-Induktivitäten Inductor shielded SMD 10 µH 0.185 Ω 1.22 A 1 pc(s) Tape on Full reel
Description
Features
- Wire wound
- Magnetic shielding
- Ferrite core
