TE Connectivity PCJ-112D3M-WG PCB relay 12 V DC 5 A 1 maker 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB relay
Coil nominal voltage
12 V DC
Control mode
monostable, 1 coil
Contact type
1 maker
Switching voltage (max.)
400 V AC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.09
5
3% = € 0.06
€ 2.03
10
5% = € 0.10
€ 1.99
50
10% = € 0.21
€ 1.88
100
20% = € 0.42
€ 1.67
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 2.09 / piece)
€ 2.09
plus VAT.
14-day return policy included
Highlights & Details
Miniature print relay PCJ, 1 closer
Technical specifications
- Product type
PCB relay
- Type
PCJ-112D3M-WG
- Coil nominal voltage
12 V DC
- Min. pick-up voltage
9 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
720 Ω
- Contact type
1 maker
- Contact material
AgNi
- Switching voltage (max.)
400 V AC
- Switching current (max.)
5 A
- Max. switching capacity
1250 VA
- Creepage distance (coil/clips)
8 mm
- Connection
Solder pins
- Min. temperature
-40 °C
- Max. temperature
+105 °C
- Length
20 mm
- Width
7 mm
- Height
15 mm
- Dim
(L x W x H) 20 x 7 x 15 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Nominal voltage (details)
12 V DC
- Nominal current (details)
5 A
- Test voltage
4000 Veff
- Switching capacity
1250 VA
- Type
PCJ-112D3M-WG
- Ambient temperature
-40 - +105 °C
Documents & Downloads
Datasheet
Datasheet 504415 TE Connectivity PCJ-112D3M-WG PCB relay 12 V DC 5 A 1 maker 1 pc(s)
Description
Narrow power relay for applications in household appliances.
Hints
Approvals: VDE, cULus.
