TE Connectivity Socket housing cable SL-156 Total number of pins 5 640250-5 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.20
50
10% = € 0.02
€ 0.18
100
15% = € 0.03
€ 0.17
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.20 / piece)
€
Only 5 Piece(s) available
Highlights & Details
Socket casing SL-156
- Content: 1 pc(s)
- No. of rows: 1
- Total number of pins: 5
Technical specifications
- Connector type
Socket, straight
- Connector system
wire-to-wire
- Series
SL-156
- Pins per row
5
- Total number of pins
5
- Pin shape
Rectangular
- Nominal current
6.50 A
- Nominal current - rounded value
6.5 A
- Content
1 pc(s)
- Dim
(L x W x H) 7.28 x 19.74 x 16.76 mm
- Factory colour
Ecru
- Height
16.76 mm
- Length
7.28 mm
- Width
19.74 mm
- Industrial packaging
No
- Connection
Crimp
- Connector contact surface
Tin plated
- Manufacturer part #
640250-5
- Type
SL-156
- Nominal voltage
250 V AC
- AWG max.
18
- AWG (min.)
30
- max. cross section
0.823 mm²
- Insulation material
Polyamide
- No. of rows
1
- Min. cross section
0.05 mm²
- Case material
Polyamide
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-55 °C
- Product type
Socket housing cable
