Tektronix 2010/E Bench multimeter Digital CAT II
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 7,057.98 / piece)
€ 7,057.98
plus VAT.
14-day return policy included
Technical specifications
- Product type
Bench multimeter
- V AC reading range (min.)
100 mV
- V AC reading range (max.)
750 V
- Amperage reading range DC (min.)
10 mA
- A DC reading range (max.)
3 A
- Amperage reading range AC (max.)
3 A
- Reading range - resistance
10 Ω - 100 MΩ
- Frequency reading range
3 Hz - 500 kHz
- Basic accuracy
0.0037 %
- Measurement type (details)
True RMS
- Height
104 mm
- Width
238 mm
- Length
370 mm
- Weight
5 kg
Manufacturer's standards (no certificate)
- Reading category
CAT II
- Voltage metering
AC
- Current reading
AC/DC
- Type
2010/E
- Display
Digital
- Dim
(L x W x H) 370 x 238 x 104 mm
Documents & Downloads
Datasheet
Datasheet 3190747 Tektronix 2010/E Bench multimeter Digital CAT II
User & Safety Instructions
User & Safety Instructions 3190747 Tektronix 2010/E Bench multimeter Digital CAT II
Description
The 7½-digit low-noise multimeter Model 2010 combines high resolution with the high speed and accuracy required for production applications such as testing precision sensors, converters, A/D and D/A converters, controllers, references, plugs, switches and relays are required. It is based on the same high-speed, low-noise A/D converter technology as the 2000, 2001 and 2002 models. The 2010 has 15 built-in measuring functions, including DCV, ACV, DCI, ACI, 2WW, 4WW, dry-running resistance, temperature (either thermocouples or RTDs), frequency, period, ratio, continuity measurement and diode test. This multi-functional design minimizes the additional device costs.
