Buy Telegärtner 100023042 Telegärtner 100023042 N/A 100023042 Plug, straight No. of pins (RJ) 8P8C 10 pc(s) 100023042 Plug,

A silver RJ45 plug with a black clip. The plug is used for data transmission and is typical of network cables.

Close-up of an Ethernet cable with stripped wires being connected into a socket. It shows the connection process.

Tool for connecting a cable to a connector by crimping and cutting. Close-up of an electrical connection.

A Telegärtner metal RJ45 plug with the plastic cover removed. Suitable for network cable connections.

1/5

Packaging type

Piece

Connector type

Plug, straight

No. of pins

8P8C

Specification

CAT 6A

Connector standard

RJ45

Datasheet (PDF)

Fast track dispatch on Wed, 7 Oct

3 Set(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number (Package size 10 pc(s))

Set(s)

Total (€ 14.29 / piece)

€ 142.85

plus VAT.

Only 3 Set(s) available

14-day return policy included

Report legal concerns

Technical specifications

Packaging type: Piece

Type: 100023042

Connector type: Plug, straight

No. of pins: 8P8C

: CAT 6A

Connector standard: RJ45

Connection: RJ45

Content: 10 pc(s)

Contact material: Ni1,2Au0,8

Width: 13.8 mm

Height: 16.2 mm

Length: 49 mm

RoHS-compliant: Yes

Features: Industrial-grade (w/o tools)

Seal type: Snap-in

Compatible with (details): CU-conductor-Ø: Solid wire: 0.51 - 0.64 mm · Stranded wire 0.46 - 0.78 mm

: IP20

Material (details): Housing: zinc die cast, nickel-plated

Type: 360° fully shielded

: 27/7 - 22/7, 26/1 - 22/1, 26/19 - 24/19

Temperature range: -40 - +70 °C

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1497078 Telegärtner 100023042 Telegärtner 100023042 N/A 100023042 Plug, straight No. of pins (RJ) 8P8C 10 pc(s) 100023042 Plug,

User & Safety Instructions

User & Safety Instructions 1497078 Telegärtner 100023042 Telegärtner 100023042 N/A 100023042 Plug, straight No. of pins (RJ) 8P8C 10 pc(s) 100023042 Plug,

Description

Of the RJ45 CONNECTOR CAT.6 A is the for time-saving and reliable pre-fabrication on site, for all networks of voice up to 10 Gigabit Ethernet. In just 60 seconds, it can be on all common types of cable - without the need for special tools. Especially with limited space in the data center can be connections centimeter quickly and cost-effectively. Cable lengths clip and the resulting space problems are a thing of the past. And thanks to its compact design, the multi-port enabled Cat 6A connector also can be used in a confined space.
Application:
Step 1: cable sheath, remove pairs sorting, untwisting and in the wires manager imports. The integrated mounting help protects the circuit board and simplifies the installation. The well visible printing, the color code according to T568A and T568B can be chosen. Wires manager with a pair of pliers together and push in the protruding Veins cut.
Step 2: installation aid and remove the circuit board with the connected wires in the connector housing. The wires management is secured against rotation designed and can only be used in the right orientation in the connector housing.
Step 3: Housing latching and the strain relief in place.

This text is machine translated.
