Telegärtner 100024918 100024918 SSMB plug Plug, straight 50 Ω 1 pc(s)
EAN:
Part number:
Item no:
Cable category
RG 316/U
Product type
SSMB plug
Connector type
Plug, straight
Impedance
50 Ω
Connection
Crimp
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
100
-
€ 12.60
3
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 70.00
Total (€ 11.90 / piece)
€ 1,190.00
plus VAT.
14-day return policy included
Highlights & Details
SSMB plug
- The plug socket - name, according to the shape of the inner conductor defined.
- This text is machine translated.
Our service for you
Technical specifications
- Cable category
RG 316/U
- Product type
SSMB plug
- Connector type
Plug, straight
- Impedance
50 Ω
- Connection
Crimp
- Content
1 pc(s)
- Cable Ø
2.70 mm
- Max. frequency
3 GHz
- Case material
Brass gold plated
- Manufacturer part #
100024918
- Insulation material
PTFE
- Contact material
Brass gold plated
- RoHS-compliant
Yes
- Temperature range
-55 - 155 °C
- Type
100024918
- Seal type
Snap-in
Documents & Downloads
Datasheet
Datasheet 1366650 Telegärtner 100024918 100024918 SSMB plug Plug, straight 50 Ω 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1366650 Telegärtner 100024918 100024918 SSMB plug Plug, straight 50 Ω 1 pc(s)
Description
The SSMB series of connectors utilizes a snap coupling and is suitable for applications up to a frequency of 3 GHz. The impedance is controlled at 50 Ω. Connector designs are available for flexible cables like RG-316 and RG-178. Styles are available for mounting to printed circuit boards using thru-hole soldered assembly. Solder and crimp techniques are used to terminate this series to the cables. Because of their small size, SSMB connectors have applications in small instruments and communication equipment.
