Teltonika RUT956 router for mobile phones

Highlights & Details

Industrial router for mobile wireless network
Ethernet / LAN, WLAN
External SMA/RP-SMA
GPS GLONASS Beidou Galileo
Black

Technical specifications

Market positioning: Industrial
WLAN standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Processor manufacturer: Meditek
Installed operating system: RutOS

Product type: Router

Type: Teltonika RUT956 Router di rete cellulare

No. of antennas: 5 x

10/100/1000 Mbps ports: 4 x

Width: 110 mm

Height: 50 mm

Depth: 100 mm

Weight: 287 g

Factory colour: Black

Built-in GPS: Yes

Built-in Glonass: Yes

No. of USB A 2.0 ports: 1 x

Material (details): Aluminium
Plastic

Memory capacity: 0.128 GB

CPU speed: 0.58 GHz

Input voltage: 9 - 30 V

Safety: 128-bit AES
192-bit AES
256-bit AES
AES CCMP
CAST
DES
EAP-TLS
HTTPS
IPSec
PEAP
SNMP
SNMPv2
SNMPv3
SSH
SSH-2
SSID
SSL/TLS
TKIP
TLS
WEP
WPA-EAP
WPA-PSK
WPA2-Enterprise
WPA2-PSK
WPA2-EAP
WPA2-SAE
Show more

Wi-Fi: Yes

UKCA: yes

Operating temperature (T-T): -40 - 75 °C

Serial ports quantity: 2

Ethernet LAN: yes

Firewall: yes

Short Message Service (SMS): yes

Dynamic DNS (DDNS): yes

USB port: yes

BeiDou: yes

MAC address filtering: yes

Galileo: yes

Quasi-Zenith Satellite System (QZSS): yes

Web-based management: yes

DHCP server: yes

Reset button: yes

Quick start guide: yes

Network bridge: yes

: yes

: 150 Mbit/s

: 50 Mbit/s

Auto MDI/MDI-X: yes

DMZ support: yes

Port forwarding: yes

Operating relative humidity (H-H): 10 - 90 %

Network address translation (NAT): yes

Number of SIM cards: 2

Built-in processor: yes

Documents & Downloads

Datasheet

Datasheet 3798870 Teltonika Teltonika RUT956 Router di rete cellulare Router

User & Safety Instructions

User & Safety Instructions 3798870 Teltonika Teltonika RUT956 Router di rete cellulare Router

Description

RUT956 is an industrial router that combines wireless, Wi-Fi and wired connectivity options with automatic WAN failover and GNSS features. Serial communication interfaces enable the integration of a wide range of devices into the entire ecosystem, while I/O and advanced RutOS software facilitate device control, automation, and event notification. Connectivity: 4G LTE (CAT 4), 3G, 2G. Dual SIM: Includes automatic failover, backup WAN, and other switching scenarios. Multiple interfaces: RS232/RS485 serial communication interfaces. GNSS: Global navigation satellite system for location services and time synchronization

This text is machine translated.

Features

Teltonika RUT956 - Wireless Router - WWAN - Wi-Fi - 3G, 4G, 2G - Desktop
Device Type : Wireless Routers - Wireless Mobile Modem - 3-Port Switch (Integrated)
Housing type : Desktop
CELL PROTOCOL : GSM, FDD LTE, TDD LTE, WCDMA
GENERATION : 3G, 4G, 2G
MOBILE FREQUENCY BAND : LTE B1, LTE B3, LTE B7, LTE B8, LTE B20, LTE B28A, LTE B38, LTE B40, LTE B41, UMTS B1, UMTS B8
WAN Ports No. : 1
Data Link Protocol: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Ethernet, Fast Ethernet
Frequency band: 2.4 GHz
Capacity : Simultaneous connections: 100
Network/transport protocol : TCP/IP, PPTP, UDP/IP, L2TPv3, NTP, ICMP/IP, IPSec, ARP, PPPoE, SMTP, FTP, DHCP, DNS, DDNS, HTTP, HTTPS, IPv4, IPv6, Telnet, OpenVPN, Wire Guard
Routing Protocol : Static IP Routing, BGP, OSPFv2, RIP-1, RIP-2, NPRP, VRRP, GRE
Platform : Clouds of Things, ThingWorx, Cumulicity, Azure IoT Hub
Remote management protocol : SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI, TR-069, JSON-RPC, MODBUS, NTP, MQTT, RADIUS
VoIP protocols : H.323, SIP
Features : Firewall, NAT support, VPN support, load balancing, WOL, Auto Uplink (Auto MDI/MDI-X), ALG support, email message, MAC address filter, operating mode "Access Point", Firmware can be updated, DDoS attack protection, WMM support, event log, QoS, IPSec NAT-T, DMVPN, SMS message, port forwarding, Reset key, DHCP relay, SNMP trap, DIN rail mountable, GRE tunneling, FOTA, tagged VLAN, SYN flooding, Captive Portal, System Log, Web Filtering, Hotspot access point capability, DMZ support, port-based VLAN, black list, white list, bridge mode, PPP, OpenVPN client, OpenVPN server, aluminum housing, VoIP pass-through support, eSIM support
Product certifications : IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g, WLAN CERTIFIED, IEEE 802.11e, IEEE 802.11n, UPnP
Power supply : AC 100-240 V (50/60 Hz)
Dimensions (width x depth x height): 11 cm x 10 cm x 5 cm
Weight: 287 g
Localization : Europe, Middle East, Africa, Korea, Thailand

Scope of delivery

RUT956-Router, 9 W-power supply, 2x mobile radio antennas (magnetic mount, SMA-plug, 3 m cable), 2x WLAN antennas, (magnetic mount, RP-SMA plug, 1.5 m cable), GNSS antenna (self-adhesive, SMA plug, 3 m cable), RS485 connection block, I/O connection block, Ethernet cable (1.5 m), SIM adapter set, QSG (quick start guide), packaging board
