TOOLCRAFT TO-9616512 Digital goniometer 360 °
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.04
3
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 26.04 / piece)
€
Highlights & Details
Toolcraft Digital Protractor
- Traffic light LED technology for the brightest display
- Flip display: The display rotates automatically during overhead measurements
- Hold function for freezing the measurement
Technical specifications
- Resolution: 0.05°
- Horizontal level measuring range: 0 to 360° (4*90°)
- Accuracy: ±0.1° at 0° and 90°: ±0.2° at the rest angles
- Measures angle in ° degrees, % percent, mm/m, IN/FT slope or pitch
- Audible tone with different beep frequency at -1.00~-0.05, 0.00, +0.05~+1.00; -89.00~-89.95, 90.00, +89.95~+89.00.
- Automatic shut-off after 3 minutes non-using
- Set Zero function, to check relative angles
- Low battery indicate
- "Traffic Light" LED technology for the brightest display
- Self checking accuracy
- Self calibration
- Hold-function to freeze the measurement
- Built in magnets at the base of V-groove aluminium
- Flip Display: The display rotates automatically with overhead measurements
- IP42 splash proof & dustproof industrial standard.
- Angle setting (max.)
360°
- Accuracy
± 0.2°
- Material
Aluminium
- Length
120 mm
- Width
49 mm
- Height
24 mm
- Dim
(L x W x H) 120 x 49 x 24 mm
- Weight
192 g
Manufacturer's standards (no certificate)
- Type
TO-9616512
- Product type
Digital goniometer
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3205504 TOOLCRAFT TO-9616512 Digital goniometer 360 °
Warranty Terms
Warranty Terms 3205504 TOOLCRAFT TO-9616512 Digital goniometer 360 °
Description
Excellent tools for the automotive, wood and mechanical industries, mechanical engineering, medicine and other areas. The V-nut base with strong magnets enables a strong attachment via a curve or cylindrical magnetic surfaces. Robust and durable application, thanks to the aluminum casing.
This text is machine translated.
This text is machine translated.
Features
- Automatic shut-off after 3 minutes
- Zero function to check relative angle
- Display for weak battery
- Traffic light LED technology for the brightest display
- Self-checking accuracy
- Self calibrating
- Hold function for freezing the measurement
- Built-in magnets on the base of the V-groove made of aluminum
- Flip display: The display rotates automatically during overhead measurements
- Powered by DC 3V (2*AAA batteries, not supplied)
- IP42 splash-protected and dust-proof according to industry standard
Scope of delivery
- Digital goniometer
- Bag
- User manual
Hints
Batteries not included.
