TP-LINK ES224G ES224G V1.6 Managed network switch 24 ports 48 Gbit/s
EAN:
Part number:
Item no:
TP-LINK Omada ES224G network switch managed L2 Gigabit Ethernet (10/100/1000) black
Highlights & Details
- Managed L2 Web-based management
- Quality of Service (QoS) support
- Number of basic switching RJ-45 Ethernet ports: 24
- MAC address table: 8000 entries Routing/switching capacity: 48 Gb/s.
- Rack installation
- AC power supply included
Technical specifications
- Energy source: AC
- Product type
Managed network switch
- LAN transfer rate
10 MBit/s
100 MBit/s
1000 MBit/s
- Transfer rate
48 Gbit/s
- Working principle
Managed switch
- 10/100/1000 Mbps ports
24 x
- MAC addresses
8000
- Width
294 mm
- Height
44 mm
- Depth
140 mm
- Type
ES224G V1.6
- Factory colour
Black
- Port
24 ports
- Power supply (details)
100 - 240 V
- UKCA
yes
- Fanless
yes
- Operating temperature (T-T)
-5 - 50 °C
- Basic switching RJ-45 Ethernet ports quantity
24
- Packet buffer memory
4 MB
- Storage relative humidity (H-H)
5 - 90 %
- Auto-negotiation
yes
- Switching capacity
48 Gbit/s
- Rack mount kit
no
- Jumbo frames
15000
- Flow control support
yes
- Quality of Service (QoS) support
yes
- Port mirroring
yes
- Link aggregation
yes
- Jumbo frames support
yes
- Multicast support
yes
- Broadcast storm control
yes
- Web-based management
yes
- Store-and-forward
yes
- Gigabit Ethernet (copper) ports quantity
24
- Cloud-managed
yes
- Firmware upgradeable
yes
- Rack mounting
yes
- MAC address table
8000 Eintragungen
- IGMP snooping
yes
- Auto MDI/MDI-X
yes
- Number of VLANs
32
- Operating relative humidity (H-H)
10 - 90 %
- VLAN support
yes
- Storage temperature (T-T)
-40 - 70 °C
- Surge protection voltage
6 kV
- Forwarding rate
35.7 Mpps
- Surge protection
yes
- User guide
yes
- Power supply included
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3799866 TP-LINK ES224G ES224G V1.6 Managed network switch 24 ports 48 Gbit/s
Description
The TP-LINK Omada ES224G V1.6 switch provides reliable and efficient network performance with 24 ports offering speeds of 10/100/1000 Base-T. With support for up to 4000 VLANs and 32 priority queues, this Ideal switch is ideal for managing large networks. With a robust MTBF of over 400,000 hours, it is designed for continuous operation in various environments and maintains its functionality in a temperature range from -5 °C to 50 °C. In order to further improve the user-friendliness, the device supports functions such as IGMP Snooping, VLAN Support and Quality of Service (QoS) for optimizing network traffic. In connection with Cloud management and a fan-less design this switch offers a silent solution for the data processing in every environment.
