TP-LINK TL-SM321B-2 Geen extra informatie beschikbaar. Transceiver board 1.25 GBit/s 2 km Module type BX
EAN:
Part number:
Item no:
TP-LINK TL-SM321B-2 V1 - SFP (mini-GBIC) transceiver module - 1GbE - 1000Base-BX - LC/UPC single mode - up to 2 km - 131
Highlights & Details
- Ethernet 1000Base-BX connectivity for high-speed 1.25 Gb/s data transfer
- Supports a wide operating temperature range from 0 °C to 70 °C.
- Digital Diagnostics Monitoring (DDM) for real-time performance tracking
- Compliant with several standards, including IEEE 802.3z and RoHS
- Developed with a long-lasting metal housing and is hot-swappable
Technical specifications
- / 1550 (RX) nm
- Product type
Transceiver board
- Transfer rate
1.25 GBit/s
- Interfaces
SFP
- Module type
BX
- Distances up to
2 km
- LAN transfer rate
1000 MBit/s
- Depth
14.6 mm
- Height
12.9 mm
- Width
55.4 mm
- Weight
60.00
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3739385 TP-LINK TL-SM321B-2 Geen extra informatie beschikbaar. Transceiver board 1.25 GBit/s 2 km Module type BX
Description
The TP-LINK TL-SM321B-2 V1 offers seamless Ethernet 1000Base-BX connectivity and ensures high-speed data transfer rates of up to 1.25 Gbps Its compatibility with Gigabit Ethernet and the support of TCP/IP and WDM (Wavelength Division Multiplexing) make it a suitable solution for efficient network communication. This SFP (Mini-GBIC) transceiver module is equipped with a robust metal enclosure and can be operated in a wide temperature range from 0 °C to 70 °C, so it can withstand harsh environmental conditions. Its hot-swap capability enables easy installation and maintenance without interrupting the network. Equipped with Digital Diagnostics Monitoring (DDM), this transceiver module provides real-time monitoring of critical parameters such as temperature, voltage, and optical signal strength. This feature ensures optimal performance and reliability of your network infrastructure.
This text is machine translated.
This text is machine translated.
Features
- TP-LINK TL-SM321B-2 V1 - SFP (mini-GBIC) transceiver module - 1GbE
- Device Type : SFP (Mini-GBIC) transceiver module - single-mode LC/UPC
- Form factor : Plug-in module
- Wiring type : 1000Base-BX
- Data transfer rate : 1.25 Gbps
- Optical wavelength : 1310 (TX) / 1550 (RX) nm
- Data Link Protocol : 1GbE
- Maximum transmission range : 2 km.
- Power supply : 3.3 V.
- Dimensions (width x depth x height): 5.54 cm x 1.46 cm x 1.29 cm
