TracoPower TDN 1-1211WI DC/DC converter (print) 12 V DC +5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 18.48
30
5% = € 0.92
€ 17.56
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 18.48 / piece)
€ 184.80
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TDN 1-1211WI
- Nominal voltage
12 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
+5 V DC
- Max. output current
200 mA
- Output current (max.) - rounded
200 mA
- Efficiency (max.)
79 %
1 W
- Insulation voltage
1600 V DC
- Enclosure
DIL
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 13.2 x 9.1 x 14.7 mm
- Height
14.7 mm
- Length
13.2 mm
- Width
9.1 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Output current (min.)
0 mA
- Weight
2.7 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3372946 TracoPower TDN 1-1211WI DC/DC converter (print) 12 V DC +5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3372946 TracoPower TDN 1-1211WI DC/DC converter (print) 12 V DC +5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3372946 TracoPower TDN 1-1211WI DC/DC converter (print) 12 V DC +5 V DC 200 mA 1 W No. of outputs: 1 x Content 1 pc(s)
Description
Compact DIL-housing (13.2 mm x 9.1 mm x 10.2 mm), 4:1 input range. Exactly regulated output voltage. Short-circuit proof, external on/off.
