TracoPower TDN 1-4822WISM DC/DC converter (print) 48 V DC +12 V DC, -12 V DC 45 mA 1 W No. of outputs: 2 x Content 1 pc(
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.00
3
4% = € 0.92
€ 20.08
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.00 / piece)
€ 21.00
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TDN 1-4822WISM
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
+12 V DC
-12 V DC
- Max. output current
45 mA
- Output current (max.) - rounded
45 mA
- Efficiency (max.)
80 %
1 W
- Insulation voltage
1600 V DC
- Enclosure
SMD
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
90 °C
- Dim
(L x W x H) 14.2 x 9.1 x 10.2 mm
- Height
10.2 mm
- Length
14.2 mm
- Width
9.1 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Output current (min.)
0 mA
- Weight
2.7 g
- Content
1 pc(s)
- Type
1-4822 TDN WISM
Documents & Downloads
Datasheet
Datasheet 1600178 TracoPower TDN 1-4822WISM DC/DC converter (print) 48 V DC +12 V DC, -12 V DC 45 mA 1 W No. of outputs: 2 x Content 1 pc(
Datasheet 1600178 TracoPower TDN 1-4822WISM DC/DC converter (print) 48 V DC +12 V DC, -12 V DC 45 mA 1 W No. of outputs: 2 x Content 1 pc(
Warranty Terms
Warranty Terms 1600178 TracoPower TDN 1-4822WISM DC/DC converter (print) 48 V DC +12 V DC, -12 V DC 45 mA 1 W No. of outputs: 2 x Content 1 pc(
Description
Compact SMD housing (13.2 mm x 9.1 mm x 10.2 mm), 4:1 input range. Exactly regulated output voltage. Short-circuit proof, external on/off.
This text is machine translated.
This text is machine translated.
