TracoPower TDR 2-0522SM DC/DC converter (SMD) 5 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 27.72
3
4% = € 1.21
€ 26.51
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 27.72 / piece)
€ 27.72
plus VAT.
Only 9 Piece(s) available
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TDR 2-0522SM
- Nominal voltage
5 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
9 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
83 mA
- Output current (max.) - rounded
83 mA
- Efficiency (max.)
82 %
2 W
- Insulation voltage
1600 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 13.55 x 12.5 x 18.9 mm
- Height
18.9 mm
- Length
13.55 mm
- Width
12.5 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
4.5 g
- Content
1 pc(s)
- Type
TDR 2-0522SM
Documents & Downloads
Datasheet
Datasheet 1509379 TracoPower TDR 2-0522SM DC/DC converter (SMD) 5 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 1509379 TracoPower TDR 2-0522SM DC/DC converter (SMD) 5 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1509379 TracoPower TDR 2-0522SM DC/DC converter (SMD) 5 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Description
Compact 2 W converter in SMD casing, input/output insulation 1600 V/DC, regulated outputs, 2:1 input range, short-circuit proof.
