TracoPower TEL 12-2413 DC/DC converter 15 V DC 0.8 A 12 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 26.04
30
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 26.04 / piece)
€ 260.40
plus VAT.
14-day return policy included
Highlights & Details
DC DC Converters
- Output 15 V DC / 0.8 A
- Power 12 W
- Solder pins
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
36.0 V DC
- Max. output current
0.8 A
- Output current (max.) - rounded
800 mA
- Min. input voltage
18.0 V DC
- Dim
(L x W x H) 23.8 x 13.7 x 14.0 mm
- Output voltage (max.)
15 V DC
- Connection
Solder pins
12 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
88 °C
- Operating temperature (min.)
-40 °C
- Weight
8.6 g
- Width
13.7 mm
- Height
14.0 mm
- Length
23.8 mm
- Type
TEL 12-2413
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3372588 TracoPower TEL 12-2413 DC/DC converter 15 V DC 0.8 A 12 W
Datasheet 3372588 TracoPower TEL 12-2413 DC/DC converter 15 V DC 0.8 A 12 W
User & Safety Instructions
User & Safety Instructions 3372588 TracoPower TEL 12-2413 DC/DC converter 15 V DC 0.8 A 12 W
Warranty Terms
Warranty Terms 3372588 TracoPower TEL 12-2413 DC/DC converter 15 V DC 0.8 A 12 W
