TracoPower TEL 15-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 45.37 / piece)
€ 45.37
plus VAT.
Highlights & Details
DC/DC converter TEL-15-series, 15 Watt
- Short-circuit-proof.
- 3 year guarantee.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEL 15-1222
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
625 mA
- Output current (max.) - rounded
625 mA
15 W
- Insulation voltage
1000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
71 °C
- Dim
(L x W x H) 50.8 x 25.4 x 10.2 mm
- Height
10.2 mm
- Length
50.8 mm
- Width
25.4 mm
- Content
1 pc(s)
15 W
- Output voltage
±12 V DC
- Output current (details)
±625 mA
- Type
TEL 15 Series
- Operating temperature
-40 - +71 °C
Documents & Downloads
Datasheet
Datasheet 154438 TracoPower TEL 15-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 154438 TracoPower TEL 15-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154438 TracoPower TEL 15-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 625 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1input range, high power density, industry-standard pinning. Shielded metal casing with isolated floor panel, cost-optimised design.
