TracoPower TEL 2-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 14.28
3
6% = € 0.79
€ 13.49
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 14.28 / piece)
€ 14.28
plus VAT.
Only 7 Piece(s) available
Highlights & Details
DC/DC converter TEL 2 series, 2 W, DIL-16
- 3-year manufacturer's guarantee
Technical specifications
- Residual ripple: (20 MHz bandwidth) 50 mVpp
- Power control ± 0.5%
- Load regulation (%): Single ±0.75 %/Dual 2.0%
- Product type
DC/DC converter (print)
- Type
TEL 2-1222
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
83 mA
- Output current (max.) - rounded
83 mA
- Efficiency (max.)
75 %
2 W
- Enclosure
DIL 16
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 23.8 x 13.7 x 7.62 mm
- Height
7.62 mm
- Length
23.8 mm
- Width
13.7 mm
- Content
1 pc(s)
2 W
- Output voltage
±12 V DC
- Output current (details)
±83 mA
- Type
TEL 2 Series
- Operating temperature
-40 - +75 °C
- Mains control
max. ±0.5 %
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 154222 TracoPower TEL 2-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 154222 TracoPower TEL 2-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 154222 TracoPower TEL 2-1222 DC/DC converter (print) 12 V DC 12 V DC, -12 V DC 83 mA 2 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1 input range , input filter in accordance with EN 55022, class A.
