TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 26.04
30
4% = € 1.13
€ 24.91
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 26.04 / piece)
€ 260.40
plus VAT.
14-day return policy included
Highlights & Details
TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
- Protected against permanent short circuit
- 3 year guarantee
Technical specifications
- Remaining ripple (20 MHz bandwidth) 60 mVpp
- Power control: ±0.5 %
- Load control (%): (Single) ±0.5 %/(Dual) ±1 %
- Product type
DC/DC converter (print)
- Type
TEL 3-2023
- Nominal voltage
20 V DC
- Min. input voltage
10 V DC
- Input voltage (max.)
30 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
100 mA
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
78 %
3 W
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-25 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 32 x 20 x 10 mm
- Height
10 mm
- Length
32 mm
- Width
20 mm
- Content
1 pc(s)
3 W
- Type
TEL 3 Series
- Operating temperature
-25 - +75 °C
- Mains control
max. ±0.5 %
Documents & Downloads
Datasheet
Datasheet 3369900 TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369900 TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369900 TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369900 TracoPower TEL 3-2023 DC/DC converter (print) 20 V DC 15 V DC, -15 V DC 100 mA 3 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1input range, EN/IEC 60950, UL/cUL 1950.
Features
- Further 2:1 input range
- Permanent short circuit.
