TracoPower TEN 15-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 55.45 / piece)
€ 554.50
plus VAT.
Technical specifications
- Control deviations: For input variation max. ± 5 %, for load variation max. ±1 %
- Ripple: 75 mV pk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 15-1223
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Efficiency (max.)
84 %
15 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 25.4 x 10.2 mm
- Height
10.2 mm
- Length
50.8 mm
- Width
25.4 mm
- Content
1 pc(s)
15 W
- Type
TEN 15 Series
- Operating temperature
(above 70 ºC power reduction 3.5 %/K) -40 - +85 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 3369953 TracoPower TEN 15-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369953 TracoPower TEN 15-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369953 TracoPower TEN 15-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369953 TracoPower TEN 15-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 500 mA 15 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1 input range, very high degree of efficiency, input filter according to EN55022, class A and FCC, level A, without external components. Continuous short circuit protection, six-sided shielded metal housing with insulated base plate, industry standard footprint. Safety/approvals standards: UL 60950-1, EN 60950-1, IEC 60950-1.
