TracoPower TEN 20-11013WIRH DC/DC converter (print) 110 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 48.73 / piece)
€ 487.30
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 20-11013WIRH
- Nominal voltage
110 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
1.33 A
- Output current (max.) - rounded
1.33 A
20 W
- Enclosure
DIP 24
- Connection
Soldering
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+75 °C
- Dim
(L x W x H) 40.60 x 25.40 x 10.20 mm
- Height
10.20 mm
- Length
40.60 mm
- Width
25.40 mm
- RoHS-compliant
Yes
- Weight
24
- Content
1 pc(s)
