TracoPower TEN 20-2411WIN DC/DC converter (print) 24 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 53.77 / piece)
€ 53.77
plus VAT.
Only 3 Piece(s) available
Technical specifications
- Ripple: 75 - 100 mV
- Product type
DC/DC converter (print)
- Type
TEN 20-2411WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
4 A
- Output current (max.) - rounded
4 A
- Efficiency (max.)
88 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50 x 25 x 10 mm
- Height
10 mm
- Length
50 mm
- Width
25 mm
- Content
1 pc(s)
20 W
- Output voltage
5 V DC
- Output current (details)
4000 mA
- Type
TEN 20-2411WIN
- Operating temperature
-40 - +85 °C
- Insulation voltage
1500 V DC
- Residual ripple
75 -100 mV
- Casing
50.8 mm (2 ") x 25.4 mm (1 ")
Documents & Downloads
Datasheet
Datasheet 156512 TracoPower TEN 20-2411WIN DC/DC converter (print) 24 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 156512 TracoPower TEN 20-2411WIN DC/DC converter (print) 24 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 156512 TracoPower TEN 20-2411WIN DC/DC converter (print) 24 V DC 5 V DC 4 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
High power density, high degree of efficiency, short-circuit proof, external on/off, shielded metallic casing with insulated base plate.
Hints
Approvals: UL, EN.
