TracoPower TEN 20-2413WIN DC/DC converter (print) 24 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 55.45 / piece)
€ 554.50
plus VAT.
Highlights & Details
DC/DC converter TEN 20-WIN-Series
- High power density in metal case 50.8 mm x 25.4 mm x 10.2 mm
- Ultra wide 4:1 input ranges
- Operating temperature range -40°C to +85°C max.
- No base load required
- E/A-INSULATION 1500 VDC
- Remote on/off
- Adjustable output voltage:
- Industry-standard pinning
- Shielded metal casing with insulated base plate
- Heat sink (TEN-HS1 as an option)
Technical specifications
- Output voltage adjustment range (models only with single output): ±10 % (with ext. Resistance)
- Control deviations: Input change: 0.2 % , load change (0-100%): 0.5 %
- Remaining ripple <75 mV pk-pk (20 MHz bandwidth)
- Short-circuit protection: Continuous, automatic Restart
- Safety standards UL/cUL 60950-1, IEC/EN 60950-1.
- Ripple < 75 - 100 m V
- Product type
DC/DC converter (print)
- Type
TEN 20-2413WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
1.33 A
- Output current (max.) - rounded
1.33 A
- Efficiency (max.)
86 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 25.40 x 50.80 x 10.20 mm
- Height
10.20 mm
- Length
25.40 mm
- Width
50.80 mm
- Weight
27 g
- Content
1 pc(s)
20 W
- Type
TEN Series
- Operating temperature
-40 - +85 °C
- Insulation voltage
1500 V DC
- Residual ripple
75 -100 mV
- Casing
50,8 mm (2 ") x 25,4 mm (1")
Documents & Downloads
Datasheet
Datasheet 3370058 TracoPower TEN 20-2413WIN DC/DC converter (print) 24 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370058 TracoPower TEN 20-2413WIN DC/DC converter (print) 24 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370058 TracoPower TEN 20-2413WIN DC/DC converter (print) 24 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370058 TracoPower TEN 20-2413WIN DC/DC converter (print) 24 V DC 15 V DC 1.33 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
High power density, high degree of efficiency, short-circuit proof, external on/off, shielded metallic casing with insulated base plate.
Scope of delivery
- DC/DC converters
Hints
Approvals: UL, EN.
