TracoPower TEN 20-4810WIR DC/DC converter (print) 48 V DC 3.3 V DC 4.5 A 20 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 77.30 / piece)
€ 773.00
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 20-4810WIR
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
3.3 V DC
- Max. output current
4.5 A
- Output current (max.) - rounded
4.5 A
- Efficiency (max.)
85 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 16.2 x 25.4 mm
- Height
25.4 mm
- Length
50.8 mm
- Width
16.2 mm
- Output voltage (max.)
3.3 V DC
- Output voltage (min.)
3.3 V DC
- Weight
30 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370363 TracoPower TEN 20-4810WIR DC/DC converter (print) 48 V DC 3.3 V DC 4.5 A 20 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370363 TracoPower TEN 20-4810WIR DC/DC converter (print) 48 V DC 3.3 V DC 4.5 A 20 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370363 TracoPower TEN 20-4810WIR DC/DC converter (print) 48 V DC 3.3 V DC 4.5 A 20 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370363 TracoPower TEN 20-4810WIR DC/DC converter (print) 48 V DC 3.3 V DC 4.5 A 20 W No. of outputs: 1 x Content 1 pc(s)
Description
20 W converter in 50.8 mm x 25.4 mm metal housing, 4:1 input range, approval according to EN 50155 for the railways. Thermal shock and virbrationsschutz according to EN 61373, input filter according to EN 55022, class B.
