TracoPower TEN 20-4823WIN DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 665 mA 20 W No. of outputs: 2 x Content 1 pc
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 50.41 / piece)
€ 504.10
plus VAT.
14-day return policy included
Technical specifications
- Ripple < 75 - 100 m V
- Product type
DC/DC converter (print)
- Type
TEN 20-4823WIN
- Nominal voltage
48 V DC
- Min. input voltage
18 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
665 mA
- Output current (max.) - rounded
665 mA
- Efficiency (max.)
88 %
20 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50 x 25 x 10 mm
- Height
10 mm
- Length
50 mm
- Width
25 mm
- Content
1 pc(s)
20 W
- Type
TEN Series
- Operating temperature
-40 - +85 °C
- Insulation voltage
1500 V DC
- Residual ripple
75 -100 mV
- Casing
50,8 mm (2 ") x 25,4 mm (1")
Documents & Downloads
Datasheet
Datasheet 3369920 TracoPower TEN 20-4823WIN DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 665 mA 20 W No. of outputs: 2 x Content 1 pc
Datasheet 3369920 TracoPower TEN 20-4823WIN DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 665 mA 20 W No. of outputs: 2 x Content 1 pc
User & Safety Instructions
User & Safety Instructions 3369920 TracoPower TEN 20-4823WIN DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 665 mA 20 W No. of outputs: 2 x Content 1 pc
Warranty Terms
Warranty Terms 3369920 TracoPower TEN 20-4823WIN DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 665 mA 20 W No. of outputs: 2 x Content 1 pc
Description
High power density, high degree of efficiency, short-circuit proof, external on/off, shielded metallic casing with insulated base plate.
Hints
Approvals: UL, EN.
