TracoPower TEN 25-2411 DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 68.90 / piece)
€ 68.90
plus VAT.
Only 3 Piece(s) available
Highlights & Details
DC/DC converter TEN 25 series, 25 Watt, 2:1 input
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: input change ±0.3 %, load change single ±0.5 %/Dual 1 %.
- Ripple: 80 mVpk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 25-2411
- Nominal voltage
24 V DC
- Min. input voltage
12.8 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Efficiency (max.)
85 %
25 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 40.6 x 9.5 mm
- Height
9.5 mm
- Length
50.8 mm
- Width
40.6 mm
- Content
1 pc(s)
25 W
- Output voltage
5 V DC
- Output current (details)
5000 mA
- Type
TEN 25-2411
- Input voltage
18–36 V DC
- Efficiency
85 %
- Operating temperature
(above 60ºC power reduction) -40 to +85 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 157267 TracoPower TEN 25-2411 DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 157267 TracoPower TEN 25-2411 DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 157267 TracoPower TEN 25-2411 DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 1 pc(s)
Description
Wide 2:1 input range, very high degree of efficiency, input filter in accordance with EN 55022, Class A and FCC, Level A with no external components. Short-circuit protection, input on/off. Industry-standard pinning, 6-sided shielded metallic casing with insulated base plates. Safety standards UL/cUL 60950-1, IEC/EN 60950-1. Adjustable output voltage ±10 % (external resistance).
