TracoPower TEN 3-0522N-HI DC/DC converter (print) 5 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 18.48
30
5% = € 0.92
€ 17.56
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 18.48 / piece)
€ 184.80
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 3-0522N-HI
- Nominal voltage
5 V DC
- Min. input voltage
4.5 V DC
- Input voltage (max.)
9 V DC
- No. of outputs
2 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
125 mA
- Output current (max.) - rounded
125 mA
- Efficiency (max.)
75 %
3 W
- Insulation voltage
3000 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.8 x 14.7 x 20.3 mm
- Height
20.3 mm
- Length
31.8 mm
- Width
14.7 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
12.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370433 TracoPower TEN 3-0522N-HI DC/DC converter (print) 5 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s
Datasheet 3370433 TracoPower TEN 3-0522N-HI DC/DC converter (print) 5 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s
User & Safety Instructions
User & Safety Instructions 3370433 TracoPower TEN 3-0522N-HI DC/DC converter (print) 5 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s
Warranty Terms
Warranty Terms 3370433 TracoPower TEN 3-0522N-HI DC/DC converter (print) 5 V DC 12 V DC, -12 V DC 125 mA 3 W No. of outputs: 2 x Content 1 pc(s
Description
2:1 input range, protected against permanent short circuit, I/O insulation 3000 V/DC, input filter EN 55022, class A. Industry-standard pins, Cost-optimized new design.
