TracoPower TEN 30-1213 DC/DC converter (print) 12 V DC 15 V DC 2 A 30 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 68.90 / piece)
€ 689.00
plus VAT.
Highlights & Details
DC/DC converter TEN 30 series, 30 Watt, 2:1 input
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: input change ±0.2 %, load change Single ±0.5 %/Dual 1 %.
- Ripple: 100 mVpk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 30-1213
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
- Output voltages
15 V DC
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Efficiency (max.)
89 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50 x 25 x 10 mm
- Height
10 mm
- Length
50 mm
- Width
25 mm
- Content
1 pc(s)
30 W
- Type
TEN Series
- Operating temperature
(above 60ºC power reduction) -40 to +85 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 3369991 TracoPower TEN 30-1213 DC/DC converter (print) 12 V DC 15 V DC 2 A 30 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3369991 TracoPower TEN 30-1213 DC/DC converter (print) 12 V DC 15 V DC 2 A 30 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369991 TracoPower TEN 30-1213 DC/DC converter (print) 12 V DC 15 V DC 2 A 30 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369991 TracoPower TEN 30-1213 DC/DC converter (print) 12 V DC 15 V DC 2 A 30 W No. of outputs: 1 x Content 1 pc(s)
Description
Small, encapsulated 30 W converter, metallic casing with insulated base plates. Wide 2:1 input range, very high degree of efficiency. Short-circuit protection, remote on/off, adjustable output voltage. Conduction disturbances EN 55022, Class A and FCC, Level A, with external capacitor. Safety standards / approvals: UL/cUL 60950-1, IEC/EN 60950-1.
