TracoPower TEN 30-2423WIN DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1 A 30 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 78.98 / piece)
€ 789.80
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 30-2423WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Efficiency (max.)
87 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 50 x 25 x 10 mm
- Height
10 mm
- Length
50 mm
- Width
25 mm
- Content
1 pc(s)
30 W
- Operating temperature
-40 - +75 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 3369937 TracoPower TEN 30-2423WIN DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1 A 30 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369937 TracoPower TEN 30-2423WIN DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1 A 30 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369937 TracoPower TEN 30-2423WIN DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1 A 30 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369937 TracoPower TEN 30-2423WIN DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1 A 30 W No. of outputs: 2 x Content 1 pc(s)
Description
The TEN 30WIN series offers very powerful 30 W DC/DC-converters with a very wide 4:1 input range in an ultra-compact casing with industry-standard pins. Other standard features of this series are the external on/off-function, the adjustable output voltage, over-voltage and short-circuit protection as well as low-voltage cut-off. Typical applications of this series lie in the field of mobile battery-operated devices, decentralized power supply in industrial and communications systems, in short at all the places where galvanically separated, exactly regulated voltages are needed and there is restricted space on the circuit board.
