TracoPower TEN 30-2433WIN DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 416 mA 30 W No. of outputs: 3 x Content 1 pc
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 88.23 / piece)
€ 882.30
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 30-2433WIN
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
3 x
- Output voltages
12 V DC
-12 V DC
- Max. output current
416 mA
- Output current (max.) - rounded
416 mA
- Efficiency (max.)
86 %
30 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 25.4 x 15.8 x 50.8 mm
- Height
50.8 mm
- Length
25.4 mm
- Width
15.8 mm
- Output voltage (max.)
12 V DC
-12 V DC
- Output voltage (min.)
12 V DC
-12 V DC
- Weight
31 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370411 TracoPower TEN 30-2433WIN DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 416 mA 30 W No. of outputs: 3 x Content 1 pc
Datasheet 3370411 TracoPower TEN 30-2433WIN DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 416 mA 30 W No. of outputs: 3 x Content 1 pc
User & Safety Instructions
User & Safety Instructions 3370411 TracoPower TEN 30-2433WIN DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 416 mA 30 W No. of outputs: 3 x Content 1 pc
Warranty Terms
Warranty Terms 3370411 TracoPower TEN 30-2433WIN DC/DC converter (print) 24 V DC 12 V DC, -12 V DC 416 mA 30 W No. of outputs: 3 x Content 1 pc
Description
30 W converter in 50.8 mm x 25.4 mm metal housing, 4:1 input range, short-circuit proof, external on/off, E/A-insulation 1500 V/DC.
