TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 105.03 / piece)
€ 525.15
plus VAT.
14-day return policy included
Highlights & Details
TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: input change (single/dual/triple) ±0.5 /1/5 %, load change (single/dual/triple) ±0.5/1/5 %
- Ripple: (5 V models Uaus/dual/triple) 50/150/75 mVpk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 40-1223
- Nominal voltage
12 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
1.4 A
- Output current (max.) - rounded
1.4 A
- Efficiency (max.)
85 %
40 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 50.8 x 50.8 x 10.2 mm
- Height
10.2 mm
- Length
50.8 mm
- Width
50.8 mm
- Content
1 pc(s)
40 W
- Type
TEN Series
- Operating temperature
-40 - +75 °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 3369987 TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369987 TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369987 TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369987 TracoPower TEN 40-1223 DC/DC converter (print) 12 V DC 15 V DC, -15 V DC 1.4 A 40 W No. of outputs: 2 x Content 1 pc(s)
Description
High power density in the 50.8 x 50.8 x 10.2 mm metal case. Further 2:1 input range, very high degree of efficiency. Protected against short circuit, industry-standard pinning, remote on/off. Safety standards UL/cUL 60950-1, EN/IEC 60950-1.
