TracoPower TEN 40-2423WI DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1.335 A 40 W No. of outputs: 2 x Content 1 pc
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 109.24 / piece)
€ 546.20
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 40-2423WI
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
1.335 A
- Output current (max.) - rounded
1.34 A
- Efficiency (max.)
86 %
40 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 45.72 x 15.8 x 27.9 mm
- Height
27.9 mm
- Length
45.72 mm
- Width
15.8 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
60 g
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3370543 TracoPower TEN 40-2423WI DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1.335 A 40 W No. of outputs: 2 x Content 1 pc
Datasheet 3370543 TracoPower TEN 40-2423WI DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1.335 A 40 W No. of outputs: 2 x Content 1 pc
User & Safety Instructions
User & Safety Instructions 3370543 TracoPower TEN 40-2423WI DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1.335 A 40 W No. of outputs: 2 x Content 1 pc
Warranty Terms
Warranty Terms 3370543 TracoPower TEN 40-2423WI DC/DC converter (print) 24 V DC 15 V DC, -15 V DC 1.335 A 40 W No. of outputs: 2 x Content 1 pc
Description
40 W in the 50.8 mm x 50.8 mm x 10 mm metal housing, 4:1 input ranges, protected against permanent short circuit, low voltage cut-off, remote on/off.
