TracoPower TEN 40-4815N DC/DC converter (print) 48 V DC 24 V DC 1.67 A 40 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 72.26 / piece)
€ 722.60
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 40-4815N
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
1.67 A
- Output current (max.) - rounded
1.67 A
- Efficiency (max.)
92 %
40 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
80 °C
- Dim
(L x W x H) 50.8 x 15.7 x 25.4 mm
- Height
25.4 mm
- Length
50.8 mm
- Width
15.7 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Weight
30 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370568 TracoPower TEN 40-4815N DC/DC converter (print) 48 V DC 24 V DC 1.67 A 40 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370568 TracoPower TEN 40-4815N DC/DC converter (print) 48 V DC 24 V DC 1.67 A 40 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370568 TracoPower TEN 40-4815N DC/DC converter (print) 48 V DC 24 V DC 1.67 A 40 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370568 TracoPower TEN 40-4815N DC/DC converter (print) 48 V DC 24 V DC 1.67 A 40 W No. of outputs: 1 x Content 1 pc(s)
Description
40 W in 25.4 mm x 50.8 mm x 10 mm housing, 2:1 input range, external on/off, permanent short circuit, input/output insulation 1500 V/DC.
