TracoPower TEN 40-4834 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 300 mA 40 W No. of outputs: 3 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 5
Total (€ 105.03 / piece)
€ 525.15
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 40-4834
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
3 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
300 mA
- Output current (max.) - rounded
300 mA
- Efficiency (max.)
86 %
40 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 50.8 x 15.8 x 50.8 mm
- Height
50.8 mm
- Length
50.8 mm
- Width
15.8 mm
- Output voltage (max.)
15 V DC
-15 V DC
- Output voltage (min.)
15 V DC
-15 V DC
- Weight
65 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3370586 TracoPower TEN 40-4834 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 300 mA 40 W No. of outputs: 3 x Content 1 pc(s)
Datasheet 3370586 TracoPower TEN 40-4834 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 300 mA 40 W No. of outputs: 3 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370586 TracoPower TEN 40-4834 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 300 mA 40 W No. of outputs: 3 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370586 TracoPower TEN 40-4834 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 300 mA 40 W No. of outputs: 3 x Content 1 pc(s)
Description
40 W in the 50.8 mm x 50.8 mm x 10 mm metal housing, 2:1 input range, insufficient temperature protection, remote on/off, heat sink (Option - not included).
