TracoPower TEN 40-7212WIR DC/DC converter (print) 110 V DC 12 V DC 3.333 A 40 W No. of outputs: 1 x Content 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 117.64 / piece)
€ 1,176.40
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 40-7212WIR
- Nominal voltage
110 V DC
- Min. input voltage
43 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
3.333 A
- Output current (max.) - rounded
3.33 A
- Efficiency (max.)
90 %
40 W
- Insulation voltage
1600 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 15.3 x 25.4 mm
- Height
25.4 mm
- Length
50.8 mm
- Width
15.3 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
32 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3370589 TracoPower TEN 40-7212WIR DC/DC converter (print) 110 V DC 12 V DC 3.333 A 40 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 3370589 TracoPower TEN 40-7212WIR DC/DC converter (print) 110 V DC 12 V DC 3.333 A 40 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3370589 TracoPower TEN 40-7212WIR DC/DC converter (print) 110 V DC 12 V DC 3.333 A 40 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3370589 TracoPower TEN 40-7212WIR DC/DC converter (print) 110 V DC 12 V DC 3.333 A 40 W No. of outputs: 1 x Content 1 pc(s)
Description
40 W in the 50.8 mm x 24.4 mm metal housing, 4:1 input range, approvals for railways according to EN 50155. Thermal shock and vibration-resistant according to EN 61373, short-circuit proof, external on/off.
