TracoPower TEN 8-2411WI DC/DC converter (print) 12 V DC 5 V DC 1.5 A 8 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 36.13 / piece)
€ 36.13
plus VAT.
Only 8 Piece(s) available
Technical specifications
- Control deviations: For input variation max. ± 2 %, for load variation max. ±0.5 % (single output)/max. ±1 % (dual output)
- Ripple: 50 mV pk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (print)
- Type
TEN 8-2411WI
- Nominal voltage
12 V DC
- Min. input voltage
12 V DC
- Input voltage (max.)
12 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
1.5 A
- Output current (max.) - rounded
1.5 A
- Efficiency (max.)
87 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 32 x 20.3 x 10.2 mm
- Height
10.2 mm
- Length
32 mm
- Width
20.3 mm
- Content
1 pc(s)
8 W
- Output voltage
5 V DC
- Output current (details)
1500 mA
- Type
TEN 8 Series
- Input voltage
9 - 36 V DC
- Efficiency
87 %
- Operating temperature
(above 70 ºC power reduction 3.5 %/K) -40 - +85 ºC °C
- Insulation voltage
1500 V DC
Documents & Downloads
Datasheet
Datasheet 157116 TracoPower TEN 8-2411WI DC/DC converter (print) 12 V DC 5 V DC 1.5 A 8 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 157116 TracoPower TEN 8-2411WI DC/DC converter (print) 12 V DC 5 V DC 1.5 A 8 W No. of outputs: 1 x Content 1 pc(s)
Conformity certificate
Conformity certificate 157116 TracoPower TEN 8-2411WI DC/DC converter (print) 12 V DC 5 V DC 1.5 A 8 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 157116 TracoPower TEN 8-2411WI DC/DC converter (print) 12 V DC 5 V DC 1.5 A 8 W No. of outputs: 1 x Content 1 pc(s)
Description
Ultra wide 4:1 input range, high degree of efficiency, input filter according to EN55022, class A and FCC, level A (with external condenser). Continuous short circuit protection, six-sided shielded metal housing with insulated base plate, external on/off, industry standard footprint. Safety/approvals standards: cUL/UL 60950-1, IEC/EN 60950-1.
