TracoPower TEN 8-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 265 mA 8 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 35.29 / piece)
€ 352.90
plus VAT.
14-day return policy included
Highlights & Details
DC/DC converter TEN 8-Series
- 3-year manufacturer's guarantee
Technical specifications
- Control deviations: For input variation max. ± 0.2 %, for load variation max. ±1 %
- Product type
DC/DC converter (print)
- Type
TEN 8-4823
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
2 x
- Output voltages
15 V DC
-15 V DC
- Max. output current
265 mA
- Output current (max.) - rounded
265 mA
- Efficiency (max.)
85 %
8 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 32 x 20 x 10 mm
- Height
10 mm
- Length
32 mm
- Width
20 mm
- Content
1 pc(s)
8 W
- Type
TEN 8 Series
- Operating temperature
(above 70 ºC power reduction 3.3 %/K) -40 - +85 ºC
- Casing
DIP-24, SMD
Documents & Downloads
Datasheet
Datasheet 3369905 TracoPower TEN 8-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 265 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 3369905 TracoPower TEN 8-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 265 mA 8 W No. of outputs: 2 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3369905 TracoPower TEN 8-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 265 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 3369905 TracoPower TEN 8-4823 DC/DC converter (print) 48 V DC 15 V DC, -15 V DC 265 mA 8 W No. of outputs: 2 x Content 1 pc(s)
Description
Wide 2:1 input voltage range, input filter according to EN 55022, class A and FCC, level A with no external components.
