TracoPower TEP 100-1211 DC/DC converter (component) 12 V DC 5 V DC 20 A 100 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 172.26 / piece)
€ 172.26
plus VAT.
Only 2 Piece(s) available
Highlights & Details
DC-DC Converter, 100 W, 12 V/5 V
- Rugged compact metal case
- Wide 2:1 input voltage range
- Full load operation up to +60°C with convection cooling
- Soft Start
- Under voltage lock-out circuit
- Reverse input voltage protection
- Output voltage adjustable
- Remote on/off
- Heat sink (Option TEP-HS1)
- 3-year product warranty
Technical specifications
- Input voltage range: 9-18 V
- Output voltage: 5 V
- Output current: 20 A
- Output power: 100 Watt
- Efficiency: 91 %
- Output voltage adjustable: +10 %/-20% (with mit ext. resistor)
- Regulation: Input variation: 0.2 % max., Load variation (0-100%): 0.3 % max
- Ripple & noise (20 MHz Bandwidth): see datasheet
- Short circuit protection: indefinite, automatic recovery
- Operating temperature range:-40°C to +75°C, Derating: see datasheet
- I/O isolation: 2250 VDC (60 s)
- Safety standards: UL/cUL 60950-1, IEC/EN 60950-1
- Product type
DC/DC converter (component)
- Type
TEP 100-1211
- Nominal voltage
12 V DC
- Min. input voltage
16.5 V DC
- Input voltage (max.)
65 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
20 A
- Output current (max.) - rounded
20 A
- Efficiency (max.)
91 %
100 W
- Insulation voltage
2250 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 57.90 x 61.00 x 12.70 mm
- Height
12.70 mm
- Length
57.90 mm
- Width
61.00 mm
- Weight
97 g
- Content
1 pc(s)
100 W
- Type
TEP 100 Series
- Operating temperature
-40 - +75 °C
- Insulation voltage
2250 V DC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1086434 TracoPower TEP 100-1211 DC/DC converter (component) 12 V DC 5 V DC 20 A 100 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1086434 TracoPower TEP 100-1211 DC/DC converter (component) 12 V DC 5 V DC 20 A 100 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1086434 TracoPower TEP 100-1211 DC/DC converter (component) 12 V DC 5 V DC 20 A 100 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1086434 TracoPower TEP 100-1211 DC/DC converter (component) 12 V DC 5 V DC 20 A 100 W No. of outputs: 1 x Content 1 pc(s)
Description
The TEP-100 Series is a family of isolated high performance dc-dc converter modules with ultra-wide 2:1 input voltage ranges which come in a rugged, sealed metal case. These converters are suitable for a wide range of applications, but the product is designed particularly also for industrial applications. A very high efficiency allows an operating temperature up to +60°C with natural convection cooling without power derating. Further features include output voltage trimming, Remote On/Off and under voltage lockout. The very wide input voltage range and reverse input voltage protection make these converters also an interesting solution for battery operated systems.
Scope of delivery
- DC-DC Converter
Hints
Heatsink not included in the delivery (please order separately).
