TracoPower TEP 100-7215UIR DC/DC converter (print) 110 V DC 24 V DC 4.2 A 100 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 176.46 / piece)
€ 176.46
plus VAT.
Only 2 Piece(s) available
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEP 100-7215UIR
- Nominal voltage
110 V DC
- Min. input voltage
14 V DC
- Input voltage (max.)
160 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
4.2 A
- Output current (max.) - rounded
4.2 A
100 W
- Connection
Soldering
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Dim
(L x W x H) 50.80 x 36.80 x 12.70 mm
- Height
12.70 mm
- Length
50.80 mm
- Width
36.80 mm
- RoHS-compliant
Yes
- Weight
64
- Content
1 pc(s)
