TracoPower TEP 160-4815 DC/DC converter (print) 48 V DC 24 V DC 6.5 A 160 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 210.08 / piece)
€ 210.08
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEP 160-4815
- Nominal voltage
48 V DC
- Min. input voltage
33 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
24 V DC
- Max. output current
6.5 A
- Output current (max.) - rounded
6.5 A
- Efficiency (max.)
92 %
160 W
- Insulation voltage
1600 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 57.9 x 17.8 x 61 mm
- Height
61 mm
- Length
57.9 mm
- Width
17.8 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Weight
105 g
- Content
1 pc(s)
- Type
TEP 160-4815
Documents & Downloads
Datasheet
Datasheet 1510087 TracoPower TEP 160-4815 DC/DC converter (print) 48 V DC 24 V DC 6.5 A 160 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510087 TracoPower TEP 160-4815 DC/DC converter (print) 48 V DC 24 V DC 6.5 A 160 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510087 TracoPower TEP 160-4815 DC/DC converter (print) 48 V DC 24 V DC 6.5 A 160 W No. of outputs: 1 x Content 1 pc(s)
Description
2:1 input range, adjustable output voltage with ext. Resistance, reverse polarity protection, heat sink (Option - not included).
This text is machine translated.
This text is machine translated.
Hints
Supplied without heatsink.
