TracoPower TEP 200-2412WIRCMF DC/DC converter (module) 24 V DC 12 V DC 15 A 200 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 415.97 / piece)
€ 415.97
plus VAT.
Only 2 Piece(s) available
Technical specifications
- Product type
DC/DC converter (module)
- Type
TEP 200-2412WIRCMF
- Nominal voltage
24 V DC
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
15 A
- Output current (max.) - rounded
15 A
- Efficiency (max.)
89 %
200 W
- Insulation voltage
1600 V DC
- Connection
Screw terminal
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
75 °C
- Dim
(L x W x H) 85 x 61 x 38.8 mm
- Height
38.8 mm
- Length
85 mm
- Width
61 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
287 g
- Content
1 pc(s)
- Type
TEP 200-2412WIRCMF
Documents & Downloads
Datasheet
Datasheet 1510099 TracoPower TEP 200-2412WIRCMF DC/DC converter (module) 24 V DC 12 V DC 15 A 200 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 1510099 TracoPower TEP 200-2412WIRCMF DC/DC converter (module) 24 V DC 12 V DC 15 A 200 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510099 TracoPower TEP 200-2412WIRCMF DC/DC converter (module) 24 V DC 12 V DC 15 A 200 W No. of outputs: 1 x Content 1 pc(s)
Description
4:1 input range, chassis mounting with screw terminal block and filter according to EN 55022, class A. Approvals for railways according to EN 50155, short-circuit proof, external on/off, adjustable output voltage with ext. Resistance, overtemperature protection.
