TracoPower TEP 200-7211UIR DC/DC converter 5 V DC 40 A 200 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 239.50 / piece)
€ 2,395.00
plus VAT.
Highlights & Details
DC/DC converter, TEP 200UIR-series
- Output 5 V DC / 40 A
- Power 200 W
Technical specifications
- Product type
DC/DC converter
- Input voltage (max.)
160 V DC
- Max. output current
40 A
- Output current (max.) - rounded
40 A
- Min. input voltage
14 V DC
- Dim
(L x W x H) 57.90 x 61 x 13 mm
- Output voltage (max.)
5 V DC
200 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+105 °C
- Operating temperature (min.)
-40 °C
- Weight
113 g
- Width
61 mm
- Height
13 mm
- Length
57.90 mm
- Type
TEP 200-7211UIR
Documents & Downloads
Datasheet
Datasheet 3373109 TracoPower TEP 200-7211UIR DC/DC converter 5 V DC 40 A 200 W
User & Safety Instructions
User & Safety Instructions 3373109 TracoPower TEP 200-7211UIR DC/DC converter 5 V DC 40 A 200 W
Warranty Terms
Warranty Terms 3373109 TracoPower TEP 200-7211UIR DC/DC converter 5 V DC 40 A 200 W
Description
The series TEP 200UIR rounds off the 200 watt range of the railway converters from TRACO Power. Important features are its compact standard metallic casing (61 mm x 57.9 mm x 13 mm) and the ultra-wide 12:1 input. This series has the relevant rail approvals according to EN 50155, EN 45545-2 and EN 61373.
This text is machine translated.
This text is machine translated.
Features
- Ultra-wide 12:1 input ranges (14 to 160 VDC)
- Compact 61 mm x 57.9 mm x 13 mm (half bridge)
- Railway approvals according to EN 50155 and EN 61373
- Fire protection according to EN 45545-2
- Operating temperature range from -40 to +105 °C.
- E/A-INSULATION 3000 VAC
- High electrical efficieny
- Remote on/off function
Scope of delivery
- 10 pieces
