TracoPower TES 1-1221V DC/DC converter (SMD) 12 V DC 5 V DC, -5 V DC 800 mA 1 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 11.76
3
6% = € 0.65
€ 11.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 11.76 / piece)
€ 11.76
plus VAT.
Only 9 Piece(s) available
Technical specifications
- Product type
DC/DC converter (SMD)
- Type
TES 1-1221V
- Nominal voltage
12 V DC
- Min. input voltage
10.8 V DC
- Input voltage (max.)
13.2 V DC
- No. of outputs
2 x
- Output voltages
5 V DC
-5 V DC
- Max. output current
800 mA
- Output current (max.) - rounded
800 mA
- Efficiency (max.)
76 %
1 W
- Insulation voltage
3000 V DC
- Enclosure
SMD
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 16.3 x 8 x 8 mm
- Height
8 mm
- Length
16.3 mm
- Width
8 mm
- Output voltage (max.)
5 V DC
-5 V DC
- Output voltage (min.)
5 V DC
-5 V DC
- Weight
2 g
- Content
1 pc(s)
- Type
TES 1-1221 V
Documents & Downloads
Datasheet
Datasheet 1510183 TracoPower TES 1-1221V DC/DC converter (SMD) 12 V DC 5 V DC, -5 V DC 800 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Datasheet 1510183 TracoPower TES 1-1221V DC/DC converter (SMD) 12 V DC 5 V DC, -5 V DC 800 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1510183 TracoPower TES 1-1221V DC/DC converter (SMD) 12 V DC 5 V DC, -5 V DC 800 mA 1 W No. of outputs: 2 x Content 1 pc(s)
Description
Compact SMD casing with industry-standard pinning, E/A-insulation 3000 V/DC, high accuracy of Pin-Co-planar intensity. Suitable for lead-free soldering process after IPC/JEDEC J-STD-020C.
