TracoPower TES 2N-2411 DC/DC converter (SMD) 24 V DC 5 V DC 400 mA 2 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 23.52
3
4% = € 1.02
€ 22.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 23.52 / piece)
€ 23.52
plus VAT.
Only 9 Piece(s) available
Technical specifications
- Control deviations: input change ±0.5 %, Last updated ±0.75 % (single output)/±2 % (dual output)
- Ripple: 50 mV pk-pk (20 MHz bandwidth)
- Product type
DC/DC converter (SMD)
- Type
TES 2N-2411
- Nominal voltage
24 V DC
- Min. input voltage
12 V DC
- Input voltage (max.)
12 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
400 mA
- Output current (max.) - rounded
400 mA
- Efficiency (max.)
77 %
2 W
- Insulation voltage
1500 V DC
- Enclosure
SMD 6
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 24 x 13.7 x 8 mm
- Height
8 mm
- Length
24 mm
- Width
13.7 mm
- Content
1 pc(s)
2 W
- Output voltage
5 V DC
- Output current (details)
400 mA
- Type
TES 2N-2411
- Input voltage
18–36 V DC
- Efficiency
77 %
- Operating temperature
(above 71 ºC power reduction 3.5 %/K) -40 - +85 °C
- Insulation voltage
1500 V DC
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 157168 TracoPower TES 2N-2411 DC/DC converter (SMD) 24 V DC 5 V DC 400 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Datasheet 157168 TracoPower TES 2N-2411 DC/DC converter (SMD) 24 V DC 5 V DC 400 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 157168 TracoPower TES 2N-2411 DC/DC converter (SMD) 24 V DC 5 V DC 400 mA 2 W No. of outputs: 1 x Content 1 pc(s)
Description
SMD package with low profile, wide 2:1 input range, input filter to EN 55022, class A and FCC, Level A continuous short circuit protected, regulated output, low ripple Safety standards/approvals according to UL/cUL 60950-1, EN 60950-1 and IEC 60950-1.
